Republic P-47D-35-RA Vital Statistics
Type: Single seat fighter/bomber
Power Plant: one 2,535-hp (wet rating) Pratt & Whitney R-2800-59W Double Wasp radial piston engine
Performance
Maximum Speed (clean)
363 mph (584km/h) at 5,000 ft
433 mph (697km/h) at 30,000 ft
Initial Climb:
3,200 ft (976m) per minute
Service Ceiling: 41,000 ft (12495m)
Range: (Max external fuel, three drop tanks) 1,800 miles (2897 km) at 195 (314 km/h) at 10,000 ft (3050m)
|
Weights:
Empty: 9,950 lb (4513 kg)
Loaded Max Takeoff): 17,500 lb (7,938 kg)
Dimensions
Span: 40 ft 9 in (12.42m)
Length: 36 ft 2 in (11.02m)
Height: 14 ft 8 in (4.47m)
Wing Area: 300 sq. ft (27.87m2)
Armament
8 X 0.5 (12.7mm) machine guns
Bomb Load: 2500 lb (1134 kg) including bombs and up to 8 rockets
|
